| No. of Cores and Nominal Cross Section | Min. Number of Wires | Nominal Insulation Thickness | Nominal Copper Tape Thickness | Nominal Steel Tape Thickness | Nominal Sheath Thickness |
Approx. Overall Diameter | Approx. Weight | Max. D.C.Resistance of Conductor at 20℃ |
||||||||
| mm² | No. | mm | mm | mm | mm | mm | kg/km | Ω/km | ||||||||
| 6/10(12)kV | ||||||||||||||||
| 3X25 | 6 | 3.4 | 0.10 | 2.5 | 2.5 | 47.4 | 3631 | 1.20 | ||||||||
| 3X35 | 6 | 3.4 | 0.10 | 2.5 | 2.6 | 49.8 | 3921 | 0.868 | ||||||||
| 3X50 | 6 | 3.4 | 0.10 | 2.5 | 2.7 | 52.5 | 4305 | 0.641 | ||||||||
| 3X70 | 12 | 3.4 | 0.10 | 2.5 | 2.8 | 56.6 | 4909 | 0.443 | ||||||||
| 3X95 | 15 | 3.4 | 0.10 | 2.5 | 2.9 | 60.7 | 5554 | 0.320 | ||||||||
| 3X120 | 15 | 3.4 | 0.10 | 2.5 | 3.0 | 63.7 | 6084 | 0.253 | ||||||||
| 3X150 | 15 | 3.4 | 0.10 | 2.5 | 3.1 | 67.1 | 6702 | 0.206 | ||||||||
| 3X185 | 30 | 3.4 | 0.10 | 2.5 | 3.2 | 71.2 | 7499 | 0.164 | ||||||||
| 3X240 | 30 | 3.4 | 0.10 | 3.15 | 3.5 | 78.3 | 9503 | 0.125 | ||||||||
| 3X300 | 30 | 3.4 | 0.10 | 3.15 | 3.6 | 83.4 | 10661 | 0.100 | ||||||||
| 3X400 | 53 | 3.4 | 0.10 | 3.15 | 3.9 | 90.1 | 12308 | 0.0778 | ||||||||
| 3X500 | 53 | 3.4 | 0.10 | 3.15 | 4.1 | 98.1 | 14303 | 0.0605 | ||||||||
| 3X630 | 53 | 3.4 | 0.10 | 3.15 | 4.3 | 106.9 | 16596 | 0.0469 | ||||||||
